Description
Dimensions: 37 1/4 H x 29 7/8 W x 28.25 D
ACCESSORIES
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Trim Kit |
Optional
JXFILLR1BB |
APPEARANCE
| Color Appearance |
Fingerprint Resistant Stainless |
| Control Knobs |
Stainless Steel Appearance
Weighted |
| Handle Color |
Stainless Steel |
| Handle Design |
Designer Style |
| Oven Door Features |
Big View Oven Window
Full-Wrapped Metal Frame
Full-Wrapped Stainless |
| Textured Steel Side Panels |
Yes |
CAPACITY
| Total Capacity (cubic feet) |
5.30 cu ft |
FEATURES
| Configuration |
Range with Storage Drawer |
| Connected Capabilities |
Amazon Alexa
DiGiorno
Fresco
IFTTT
Innit
The Google Assistant
Sonos
Google Home |
| Control Location |
Front |
| Control Type |
Digital Temperature Display
Electronic Oven Controls
Touch Controls |
| Cooking System |
True Convection with Precise Air |
| Cooking Technology |
Convection |
| Cooktop Burner Type |
Radiant
Smoothtop |
| Cooktop Surface |
Edge-to-Edge
Gray Patterned Ceramic Glass
One-Piece Upswept |
| Cooktop Type |
Radiant Smoothtop |
| Drawer Type |
Storage |
| Dual Ring Burners |
Yes |
| Element – Center |
6″ 100W Warming Zone |
| Element – Left Front |
8″/5″ 1900W Bridge |
| Element – Left Rear |
8″ 2000W Bridge |
| Element – Right Front |
12”/9”/6” 3600W Power Boil |
| Element – Right Rear |
6″ 1200W |
| Fuel Type |
Electric |
| Heating Element “ON” Indicator Light |
1 |
| Hot Surface Indicator Lights |
5 |
| Melt Setting |
Yes |
| OU Certified |
No |
| Oven Cleaning Type |
Steam Clean |
| Oven Control Features |
Audible Preheat Signal
Electronic Clock & Kitchen Timer
Fast Preheat
Hi / Low Broil
Temperature Probe
Oven “ON” Light
Preheat Notification
Steam Clean
Auto Oven Shut-Off with Override
Auto Recipe Conversion
C° or F° Programmable
Certified Sabbath Mode
Chef Connect
Control Lock Capability
Delay Bake Option (Time Cook)
Delay Clean Option |
| Oven Cooking Modes |
No Preheat Air Fry
Baked Goods
Convection Bake
Convection Roast
Frozen Pizza
Frozen Snacks
Proof
Warming |
| Oven Features |
6-Pass Broil Element
Hidden Bake |
| Oven Interior |
1 Halogen Light |
| Oven Rack Features |
3 Flat Nickel Racks |
| Oven Rack Positions (Single or Upper/Lower) |
6 |
| Power Boil Burner |
Yes |
| Product Type |
Slide-In Single Oven |
| Sabbath Mode |
Yes |
| Storage Drawer Features |
Removable Full-Width |
| WiFi Connect |
Built-In |
POWER / RATINGS
| Amp Rating at 208V |
40 |
| Amp Rating at 240V |
40 |
| Bake Wattage |
2850W |
| Broiler Wattage |
3800W |
| Electrical Requirements |
208/240V ; 60Hz ; 40A |
| KW Rating at 208V |
11.6 |
| KW Rating at 240V |
15.5 |
WEIGHTS & DIMENSIONS
| Approximate Shipping Weight |
221 lb |
| Cabinet Width |
30 in |
| Depth with Door Open |
47 7/8 in |
| Depth Without Handle |
25 1/2 in |
| Height to Cooking Surface (in.) |
35 3/4 – 36 1/2 |
| Net Weight |
200 lb |
| Oven Interior Dimensions (W x H x D) (in.) |
24-1/8 x 19-1/2 x 19-3/8 |
| Overall Depth |
28.25 in |
| Overall Height |
37 1/4 in |
| Overall Width |
29 7/8 in |
