Description

APPEARANCE
Color Appearance Black
Control Knobs Gloss Black
Frameless Yes
FEATURES
Control Location Front Center
Control Type Knob (Infinite switch)
Cooktop Burner Type 5 Ribbon
Smoothtop
Cooktop Control Features Fifth Element Warming Zone
Cooktop Surface Black Ceramic Glass
Cooktop Type Radiant Smoothtop
Dishwasher Safe Knobs Yes
Dual Ring Burners Yes
Element – Center 12″/9″ 2700W dual
Element – Left Front 7″ 1500W
Element – Left Rear 6″ 120W Warming Zone
Element – Right Front 8″ 2500W Power Boil
Element – Right Rear 6″ 1200W (Melt)
Fuel Type Electric
Indicator Lights 5 Hot Surface
Surface Element “ON”
Red
Melt Setting Yes
Power Boil Burner Yes
Product Type Cooktop
POWER / RATINGS
Electrical Requirements 208/240V ; 60Hz ; 40A
Hertz 60
Max. Connected Load (kW) at 208V 7.1
Max. Connected Load (kW) at 240V 9.0
Max. Current Draw (Amps) at 208V 34.3
Max. Current Draw (Amps) at 240V 37.5
Recommended Circuit Breaker (Amps) at 208V 40
Recommended Circuit Breaker (Amps) at 240V 40

WEIGHTS & DIMENSIONS
Approximate Shipping Weight 53 lb
Cabinet Width 36 in
Cooktop Size 36 in
Cutout Depth (in) 19 1/8 in
Cutout Height (in) 5.5625
Cutout Width (in) 33.875
Net Weight 46 lb
Overall Depth 20 3/8 in
Overall Height 3 3/8 in
Overall Width 36 in
